【Product Applications】

The H41H and H41Y lift check valve series are suitable for water, steam, gas, corrosive media, food, oil, pharmaceuticals, etc.

【Product Features】

1. The valve disc stroke is only 1/3 of the valve disc diameter, greatly reducing the valve disc closing time and effectively reducing water hammer pressure in lift check valves.

2. The sealing surface is made of alloy steel or hard alloy, and the sealing pair materials are reasonably matched, resulting in a long service life.

【Standards】

Design Specifications: GB/T 12235 BS 1868

Structural Length: GB/T 12221 ASME B16.10

Flange Connection: GB/T 9113 ASME B16.5

Testing and Inspection: GB/T 13927 API 598 API 6D
